Select ISO Location
The Select ISO Location page allows you to provide the details of a bootable operating system ISO file.
NOTE: Providing the ISO file details is applicable only for target servers that do not have virtual I/O identities. Typically,
servers with virtual I/O identities are expected to boot from a SAN.
The fields displayed on the Select ISO Location page of the Create Compute Pool Wizard are described in the following table.
Table 83. Select ISO Location
Field Description
Boot Compute Pool from Network ISO Select to boot devices included in the compute pool from an
operating system ISO file.
ISO Filename Provide the name of the ISO file.
Share IP Provide the IP address of the network share where the ISO file
is available.
Share Name Provide the name of the network share where the ISO file is
available.
Related links
Create Compute Pool Wizard
Select Virtual I/O Pool
The Select Virtual I/O Pool page allows you to select the method of assigning the virtual I/O identity on the target servers.
The fields displayed on the Select Virtual I/O Pool page are described in the following table.
Table 84. Select Virtual I/O Pool
Field Description
User-defined I/O assignment Select to manually assign the virtual I/O identities.
Automatic I/O assignment Select to allow OpenManage Essentials to automatically assign
virtual I/O identities to the target servers. The virtual I/O
identities are assigned from the virtual I/O pool that you select.
NOTE: The virtual I/O pools are available for selection
only if you have already created the virtual I/O pools.
Related links
Create Compute Pool Wizard
Select Devices
The Select Devices page allows you to select the servers you want to include in the compute pool.
NOTE: Only servers that you have added to the Repurpose and Bare Metal group are available for selection.
The Select Devices page displays a tree-view of the servers that you can include in the compute pool. You can select one or more
servers for inclusion in the compute pool.
Related links
Create Compute Pool Wizard
169
