Create Virtual I/O Pool Wizard
Ethernet Identities
The Ethernet Identities page allows you to generate or import Media Access Control (MAC) addresses to the virtual I/O pool. MAC
addresses are required for Ethernet (LAN) communications.
The fields displayed on the Ethernet Identities page of the Create Virtual I/O Pool Wizard are described in the following table.
Table 73. Ethernet Identities
Field Description
Include MAC addresses in this pool Select to include MAC addresses in the virtual I/O pool.
Specify a prefix to allocate from Select to specify a prefix for the MAC addresses that will be
generated. Type the predefined values in the appropriate fields.
Number of predefined octets Set the number of octets that you want to predefine in the
MAC addresses that will be generated.
NOTE: You can only prefix 3 to 5 octets in the MAC
addresses.
Import from file Select to import MAC addresses from a .csv file.
Import Click to open the wizard used to import MAC addresses from
a .csv file.
NOTE: The .csv must include only one address or
identity per line.
View Click to view the MAC addresses in the virtual I/O pool.
NOTE: You can only view MAC addresses that you have
already imported from a .csv file.
Related links
Create Virtual I/O Pool Wizard
FCoE Node Name Identities
The FCoE Node Name Identities page allows you to generate or import World Wide Node Name (WWNN) identities to the virtual
I/O pool. WWNN identities are required for Fibre Channel (FC) and Fibre Channel over Ethernet (FCoE) communications.
The fields displayed on the FCoE Node Name Identities page of the Create Virtual I/O Pool Wizard are described in the following
table.
Table 74. FCoE Node Name Identities
Field Description
Include Fibre Channel WWNN Identities in the pool Select to include WWNN identities in the virtual I/O pool.
Specify a prefix to allocate from Select to specify a prefix for the WWNN identities that will be
generated. Type the predefined values in the appropriate fields.
Number of predefined octets Set the number of octets that you want to predefine in the
WWNN identities that will be generated.
NOTE: You can only prefix 3 to 7 octets in the WWNN
identities.
Import from file Select to import WWNN identities from a .csv file.
164
