Table 68. Device Configuration Template Details
Field Description
Undo Click to undo the changes made to the configuration template.
Save Click to save the changes to the configuration template.
Grouped by Displayed if you have chosen to display the attributes as groups.
Total Displays the total number of attributes in the template.
Modified Displays the number of attributes you have modified.
Deploy Select to deploy an attribute. If you do not select an attribute,
the attribute value is not deployed on the target device and the
current value will be retained on the target device. You can
select all the attributes in the template by selecting the check
box in the Deploy column header.
Modified Displays if you have modified the value of an attribute.
Section Displays the component that the attribute belongs to. For
example, iDRAC, BIOS, NIC, and so on.
Instance Displays the instance of the component that the attribute
belongs to.
Attribute Name Displays the name of the attribute.
Value Displays the value of the attribute.
Dependencies Displays if the attribute is dependent on any other attributes. To
edit a dependent attribute, you must first set the primary
attribute.
Destructive Displays if deploying the attribute may result in destructive
changes to the device configuration including performance,
connectivity, and ability to boot the device.
Group Displays the group the attribute belongs to.
Related links
Viewing the Device Configuration Template Attributes
IOA VLAN Attributes
The fields displayed in the IOA VLAN Attributes pane of the Deployment Portal are described in the following table.
Table 69. IOA VLAN Attributes
Field Description
Undo Click to undo the changes made to the IOA template.
Save Click to save the changes to the IOA template.
Total Displays the total number of attributes.
Modified Displays the number of attributes that you have modified.
Deploy Select to deploy an attribute. If an attribute is not selected, the
attribute value will not be deployed on the target device and the
161
