1. Optional: Click Assign Identities to assign virtual I/O identities from the virtual I/O pool.
2. On the Results prompt, click OK. The Identity Assignments tab is displayed.
m. (For IOA VLAN configuration deployment only) Click the IOA VLAN Attributes tab to edit the IOA VLAN attributes for the
selected template.
n. Select the Deploy check box for the attributes that you want to deploy.
o. Type the values for the tagged VLANs and untagged VLAN.
p. Click Save.
q. Click Next.
8. On the Set Schedule page:
a. Select either Run now, or click the calendar icon and select the date and time you want to run the task.
b. Under Execution Credentials, type the credentials of the iDRAC that have Administrator privileges.
c. (Only for IOA VLAN configuration deployment) Under IOA Credentials, type the credentials that have Administrator
privileges on the IOA.
d. Click Next.
9. On the Preview page:
a. Optional: Click Preview to verify if the attributes of the device configuration template will be deployed successfully on the
target devices.
b. Click Next.
10. On the Summary page, review the information that you have provided, and then click Finish.
The Deploy Template warning is displayed.
11. If you want to continue the deployment, click Yes.
The Deploy Template task is created and the task runs based on the schedule you have selected. You can double-click the task in
Task Execution History to view the task execution details. After the deployment is completed successfully, the template deployed
icon and the text, Deployed, are displayed along with the device name in the compute pool.
NOTE: On stateless deployment for FCoE protocol, the first octet for WWNN will be 20:00 and the first octet for the
WWPN will be 20:01. The remaining octets will be the same as the virtual FIP MAC address.
Related links
OpenManage Essentials — Server Configuration Management License
Device Requirements for Deployment and Compliance Tasks
Compute Pools
Automatic Locking of a Compute Pool
Automatic Locking of a Compute Pool
After the first successful deployment of any server in a compute pool, the compute pool is automatically locked. When a compute
pool is locked, the associated device configuration template and the virtual I/O pool are also locked. A lock icon is displayed in
the user interface to indicate that the resource is locked. Locking of the compute pool ensures that all servers in the pool utilize the
same device configuration template and virtual I/O pool. You can only perform the following on a locked compute pool:
• View the definitions of the compute pool
• Add or remove servers from the compute pool
• Deploy servers that are members of the compute pool
NOTE: If you want to use a locked device configuration template for other purposes, you can clone and use the device
configuration template.
