NOTE: You can import up to 1000 identities using a .csv file. The .csv file must have a column titled Name or
Value.
1. Click Import.
2. On the Import Wizard, click Import.
3. Browse and select the .csv file and click Open. The Import Results window is displayed.
4. Close the Import Results window and the Import Wizard, and then click Next.
Figure 26. Sample .csv file with iSCSI IQN identities
8. On the Summary page, review the definitions that you provided for the I/O identity types, and then click Finish.
The virtual I/O pool that you created is displayed under Virtual I/O Pools on the left pane.
Related links
Virtual I/O Pools
Create Virtual I/O Pool Wizard
Editing a Virtual I/O Pool
You can edit a virtual I/O pool to add ranges that you had not specified earlier, add a new I/O identity type, or delete identity type
ranges that have not been assigned to any compute pool.
To edit the definitions of a virtual I/O pool:
1. Click Deployment.
The Deployment Portal is displayed.
2. On the left pane, under Virtual I/O Pools, right-click a virtual I/O pool, and then click Edit.
The Create Virtual I/O Pool Wizard is displayed.
3. Make the required changes to the definitions on the appropriate pages of the wizard.
4. On the Summary page, click Finish.
The changes you made to the virtual I/O pool are saved.
Related links
Virtual I/O Pools
Create Virtual I/O Pool Wizard
Viewing the Definitions of a Virtual I/O Pool
To view the definitions of a virtual I/O pool:
1. Click Deployment.
The Deployment Portal is displayed.
2. On the left pane, under Virtual I/O Pools, right-click a virtual I/O pool, and then click View.
The Create Virtual I/O Pool Wizard is displayed.
3. Click Next to view the various I/O identity definitions of the virtual I/O pool.
Related links
Virtual I/O Pools
Create Virtual I/O Pool Wizard
142
