7. Click Finish.
Related links
Auto Deploying Device Configurations
Manage Auto Deployment Credentials
Adding a Discovery Range for Auto Deployment
You can create a discovery range for the auto deployment task through either the Auto Deployment tab or the Discovery and
Inventory portal.
Before you can add a discovery range through the Auto Deployment tab, you must setup an auto deployment task.
To add a discovery range through the Auto Deployment tab:
1. Click Deployment → Deployment Portal.
The Repurpose and Bare Metal Devices tab is displayed in the right pane.
2. In the right pane, click the Auto Deployment tab, and then click Add Discovery Range.
The Discover Devices wizard is displayed.
3. Follow the instructions from step 2 to step 5 in Creating a Discovery and Inventory Task to create the discovery range.
The discovery range is created in the Discovery and Inventory portal.
Related links
Auto Deploying Device Configurations
Auto Deployment
Removing Devices From an Auto Deployment Task
If you do not want to perform auto deployment on a particular devices, you can remove those devices from the auto deployment
task.
To remove devices from an auto deployment task:
1. Click Deployment → Deployment Portal.
The Repurpose and Bare Metal Devices tab is displayed in the right pane.
2. On the right pane, click the Auto Deployment tab, and select the devices you want to remove.
3. Perform one of the following:
• Click Remove Selected Devices.
• Right-click and select Delete.
4. On the confirmation dialog box, click Yes.
The devices are removed from the Auto Deployment tab.
Related links
Auto Deployment
Importing Device Specific Attributes
You can also import the device specific attributes for deployment, if you already have a .csv file that includes the attributes.
Before you begin, make sure that the .csv file that you want to import meets the requirements specified in Import File
Requirements.
To import the attributes:
1. On the Edit Attributes page of the Deployment Template Wizard or Setup Auto Deployment wizard, click Import/Export.
The Import/Export Device Specific Attributes window is displayed.
2. Click Import.
The import confirmation dialog box is displayed.
3. Click Yes.
136
