The Boot to Network ISO task is created and the task runs based on the schedule you have selected. You can double-click the task
in Task Execution History to view the task execution details. After the target server boots to the network ISO image, you must
launch the iDRAC virtual console and select the options for deploying the ISO image.
Related links
Deploy Template Wizard
Device Configuration Setup Wizard
Device Requirements for Deployment and Compliance Tasks
Removing Devices From the Repurpose and Bare Metal Devices Group
You can remove devices from the Repurpose and Bare Metal Device group after the device configuration deployment, network
ISO image deployment, or auto deployment task is complete.
To remove devices from the Repurpose and Bare Metal Devices group:
1. Click Deployment → Deployment Portal.
2. In the Repurpose and Bare Metal Devices tab, select the devices you want to remove.
3. Perform one of the following:
• Click Remove Selected Devices.
• Right-click and select Remove.
4. On the confirmation dialog box, click Yes.
The devices are removed from the Repurpose and Bare Metal Devices tab in the right pane, and in the Repurpose and Bare
Metal Devices group in the device tree.
Related links
Repurpose and Bare Metal Devices
Auto Deploying Device Configurations
The Setup Auto Deployment task enables you to deploy either a device configuration or network ISO image on target devices that
you will discover at a later time. For example, if your company has ordered 500 systems that are expected to be delivered through
the next two weeks, you can create the Setup Auto Deployment task that runs periodically and deploys the configuration after the
devices are discovered.
When creating the task, you must import a .csv file that includes the Service Tags or node IDs of target devices on which you want
to deploy the configuration. By default, the Setup Auto Deployment task is run every 60 minutes to identify if the target devices
have been discovered. If a target device is discovered, the device configuration is automatically deployed to the target device. You
can also modify the recurrence of the Setup Auto Deployment task based on your preference.
NOTE: If you create auto deployment tasks in OpenManage Essentials version 2.0 or 2.0.1 and then upgrade to version
2.1 or version 2.2, the auto deployment tasks do not run successfully. In this scenario, it is recommended that you
recreate the auto deployment tasks after the upgrade to version 2.1 or version 2.2.
NOTE: Auto Deployment feature is not applicable for IOA templates.
Related links
Configuring Auto Deployment Settings
Setting Up Device Configuration Auto Deployment (Bare Metal Deployment)
Managing Auto Deployment Credentials
Adding a Discovery Range for Auto Deployment
Configuring Auto Deployment Settings
The Auto Deployment Settings allows you to perform the following:
132
