8. On the Set Schedule page:
a. Select either Run now, or click the calendar icon and select the date and time you want to run the task.
b. Under Execution Credentials:
• For server configuration deployment — type the credentials that have Administrator privileges on the iDRAC of the
target servers.
• For chassis configuration deployment — type the credentials that have Administrator privileges on the CMC of the
target chassis.
c. (Only for IOA VLAN configuration deployment) Under IOA Credentials, type the credentials that have Administrator
privileges on the IOA.
d. Click Next.
9. On the Preview page:
a. Optional: Click Preview to verify if the attributes of the device configuration template will be deployed successfully on the
target devices.
b. Click Next.
10. On the Summary page, review the information that you have provided, and then click Finish.
The Deploy Template warning is displayed.
11. If you want to continue the deployment, click Yes.
The Deploy Template task is created and run based on the schedule you have selected. You can double-click the task in Task
Execution History to view the task execution details.
Related links
Deploy Template Wizard
Device Configuration Setup Wizard
OpenManage Essentials — Server Configuration Management License
Device Requirements for Deployment and Compliance Tasks
Deploying IOA Configuration Template
The Deploy Template task allows you to deploy an IOA configuration template on a target device.
Before you begin deploying an IOA device configuration template, ensure that:
• The deployment file share is configured. For more information, see Configuring the Deployment File Share.
• The target devices are added to the Repurpose and Bare Metal Devices group or a compute pool. For more information, see
Adding Devices to the Repurpose and Bare Metal Devices Group.
• You have created a device configuration template from an IOA.
• The target devices meet the requirements specified in Device Requirements for Deployment and Compliance Tasks.
NOTE: Ensure that the IOA template that you want to import has not been edited after it was created. Editing an IOA
template, compromises the integrity of the template. Therefore, deploying the edited IOA template will result in a failure.
CAUTION: Deploying a configuration template on a device may result in potentially destructive changes to the device
configuration including performance, connectivity, and ability to boot the device.
To deploy the IOA configuration template:
1. Click Deployment.
The Deployment Portal is displayed.
2. Perform one of the following:
• In the Common Tasks pane, click Deploy Template.
• In the Templates pane, right-click the IOA template that you want to deploy, and click Deploy.
• In the Compute Pools pane, right-click a compute pool that has the target device, and then click Deploy.
The Deploy Template Wizard wizard is displayed.
129
