NOTE: The device-specific attributes and virtual I/O identity attributes of a device configuration template can only be
viewed in the Edit Attributes tab of the Deploy Template Wizard.
1. Perform one of the following:
• Click Deployment → Deployment Portal.
• Click Manage → Configuration → Device Compliance Portal.
2. In the Templates pane, click either a sample template or a template that you created.
The attributes of the template are displayed in the Attributes tab in the right pane. The total number of attributes in the
template is displayed at the top right of the Attributes tab.
NOTE: IOA templates can only be created and deployed. The IOA templates that you create are displayed only in the
Deployment Portal.
NOTE: If the device configuration template was created from a blade server, the right pane also displays the IOA VLAN
Attributes tab. This tab contains the VLAN attributes that you can deploy on the IOA while deploying a blade server.
Related links
Managing Device Configuration Templates
Device Configuration Template Details
Cloning a Device Configuration Template
You can clone a device configuration template to create a template that you can edit and deploy.
To clone a device configuration template:
1. Perform one of the following:
• Click Deployment → Deployment Portal.
• Click Manage → Configuration → Device Compliance Portal.
2. In the Templates pane, right-click a template, and then click Clone.
The Clone Configuration Template window is displayed.
3. Type a name for the template, and click Ok.
The cloned template is displayed in the Templates pane under the sample templates.
Related links
Managing Device Configuration Templates
Editing a Device Configuration Template
You can edit a device configuration template to make the changes you want on the template before you deploy or use the template
for verifying compliance.
NOTE: Editing of an IOA template is not supported.
To edit a device configuration template:
1. Perform one of the following:
• Click Deployment → Deployment Portal.
• Click Manage → Configuration → Device Compliance Portal.
2. In the Templates pane, right-click a template, and then click Edit.
The attributes of the template are displayed in the Attributes tab in the right pane.
3. If you do not want to deploy a particular attribute in the template and want to retain the current attribute value on the target
device, clear the check box for that attribute in the Deploy column.
4. To select or clear all the attributes in the template, select or clear the check box that is displayed next to the Deploy column
title.
126
