NOTE: IOA templates can only be created and deployed. The IOA templates that you create are displayed only in the
Deployment Portal.
Related links
Create Template Wizard
Device Requirements for Deployment and Compliance Tasks
Adding Devices to the Repurpose and Bare Metal Devices Group
Adding devices to the Repurpose and Bare Metal Devices group is a prerequisite for deploying either a configuration template or a
network ISO image on those devices.
CAUTION: Ensure that only the appropriate devices are added to the repurpose and bare metal devices group. After
deploying a configuration template on a repurpose and bare metal device, it may not be possible to revert the device to
its original configuration.
NOTE: Servers that you want to add to the Repurpose and Bare Metal Device Group must have the
OpenManage
Essentials — Server Configuration Management License
installed. For more information, see OpenManage Essentials
— Server Configuration Management License.
To add devices to the Repurpose and Bare Metal Devices group:
1. Click Deployment → Deployment Portal.
2. In the Repurpose and Bare Metal Devices tab, click Modify Devices.
The Modify Devices of the Repurpose and Bare Metal Device Group window is displayed.
3. From the All Applicable Devices tree, select the devices that you want to add to the Repurpose and Bare Metal Devices
group.
4. Click Finish.
The devices that you added are listed in the Repurpose and Bare Metal Devices tab in the right pane, and in the Repurpose
and Bare Metal Devices group in the device tree.
Related links
Deploying a Device Configuration Template (Bare Metal Deployment)
Getting Started for Device Configuration Deployment
Repurpose and Bare Metal Devices
Managing Device Configuration Templates
The device configuration templates contain various attributes of a server, chassis, or IOA. Before you use the device configuration
template for either deployment or verification of the compliance status, you can:
• View the attributes of a device configuration template
• Clone a device configuration template
• Edit a device configuration template
• Export a device configuration template
• View the properties of a device configuration template
Related links
Viewing the Device Configuration Template Attributes
Cloning a Device Configuration Template
Editing a Device Configuration Template
Exporting a Device Configuration Template
Viewing the Device Configuration Template Attributes
To view the device configuration template attributes:
125
