NOTE: If the deployment file share settings are not configured, a message stating that One or more settings
require configuring for this action is displayed. If you click OK, the File Share Settings window is
displayed. After you configure the file share settings, the
Create Template Wizard is displayed.
3. In the Name field, type a name for the template.
4. Click Create from File.
5. Click Browse.
6. Navigate and select the configuration file, and click Open.
7. Click Finish.
The configuration template that is created is displayed in the Templates pane.
NOTE: IOA templates can only be created and deployed. The IOA templates that you create are displayed only in the
Deployment Portal.
Related links
Create Template Wizard
Device Requirements for Deployment and Compliance Tasks
Creating a Device Configuration Template From a Reference Device
You can create a device configuration template from a server, chassis, or an IOA that you have discovered.
Before you create a configuration template from a reference device, ensure that:
• The deployment file share is configured. For more information, see Configuring the Deployment File Share.
• You are creating a device configuration template from a device that meets the requirements specified in Device Requirements
for Deployment and Compliance Tasks.
To create a device configuration template from a reference device:
1. Perform one of the following:
• Click Deployment → Deployment Portal.
• Click Manage → Configuration.
2. Perform one of the following:
• In the Common Tasks pane, click Create Template.
• In the Templates pane, right-click Server Template, Chassis Template, or IOA Template, and then click Create Template.
• In the Common Tasks pane, click either Getting Started for Deployment or Getting Started for Compliance → Create
Template.
The Create Template window is displayed.
NOTE: If the deployment file share settings are not configured, a message stating that One or more settings
require configuring for this action
is displayed. If you click OK, the File Share Settings window is
displayed. After you configure the file share settings, the Create Template Wizard is displayed.
3. Type a Name for the template.
4. Select the device type (Server, Chassis, or IOA) and perform one of the following:
• Select a device from the All Applicable Devices tree.
• Search for a device by using the Search Devices box.
5. Under Execution Credentials, provide the device credentials that have Administrator rights, and click Finish.
6. In the task submission message, click Ok.
A Create Template task is created in the Tasks tab in the right pane. You can view the status of the configuration template in Task
Execution History in the right pane. You can double-click the task in Task Execution History to view the task execution details.
The configuration template that is created is displayed in the Templates pane.
124
