• Click Manage → Configuration. In the Common Tasks pane, click File Share Settings.
The File Share Settings window is displayed.
2. Type the domain\user name and password of the server running OpenManage Essentials in the appropriate fields.
3. Click Apply.
If the file share is configured correctly, the File Share Status displays Ok.
Related links
Getting Started for Device Configuration Deployment
Creating a Device Configuration Template
The Create Template task creates a device configuration template that includes the attributes of a server, chassis, or an IOA. Using
the device configuration template, you can:
• Deploy the configuration on another server, chassis, or an IOA.
• Verify the compliance of either a server or chassis to the configuration template.
NOTE: Compliance tasks are not supported for IOA templates.
You can create a device configuration template from:
• A device configuration file.
• A server or chassis that you have discovered.
Related links
Creating a Device Configuration Template From a Device Configuration File
Creating a Device Configuration Template From a Reference Device
Creating a Device Configuration Template From a Device Configuration File
You can create a device configuration template from an existing server configuration (.xml) file, chassis configuration (.ini) file, or
IOA configuration (.txt) file.
Before you create a configuration template from a device configuration file, ensure that:
• The deployment file share is configured. For more information, see Configuring the Deployment File Share.
• The configuration file is from a device that meets the requirements specified in Device Requirements for Deployment and
Compliance Tasks.
• For IOA templates only –– Ensure that the IOA template that you want to import has not been edited after it was created.
Editing an IOA template, compromises the integrity of the template. Therefore, deploying the edited IOA template will result in a
failure.
To create a device configuration template from a device configuration file:
1. Perform one of the following:
• Click Deployment → Deployment Portal.
• Click Manage → Configuration.
2. Perform one of the following:
• In the Common Tasks pane, click Create Template.
• In the Templates pane, right-click Server Template, Chassis Template, or IOA Template, and then click Create Template.
• In the Common Tasks pane, click either Getting Started for Deployment or Getting Started for Compliance → Create
Template.
The Create Template Wizard is displayed.
123
