Getting Started for Device Configuration Deployment
Before you can deploy a device configuration to target devices, you must:
1. Configure the deployment file share on the server running OpenManage Essentials.
2. Add target devices to the Repurpose and Bare Metal Devices group.
Related links
Overview of Bare Metal Deployment
Overview of Stateless Deployment
Configuring the Deployment File Share
Adding Devices to the Repurpose and Bare Metal Devices Group
Overview of Bare Metal Deployment
The steps that you must perform to deploy a device configuration template on target devices are as follows:
1. Create a device configuration template — Use the Create Template task in the Common Tasks pane to create a device
configuration template. You can choose to create the template from either a configuration file or a reference device.
2. Edit the device configuration template — Select the template from the Templates pane, and edit the desired configuration
attributes displayed in the right pane.
3. Deploy the device configuration template on target devices — Use the Deploy Template task in the Common Tasks pane
to select the template, target devices, edit device-specific attributes, and then deploy the configuration attributes. You can
also use the Setup Auto Deployment task to deploy a device configuration template on devices that you will be discovering
later.
NOTE: If the hardware of the device from which the device configuration template was created and the hardware of the
deployment targets are identical, it enhances the possibility of the attributes being deployed successfully. If the
hardware is not entirely identical, the deployment task may not complete successfully. However, the attributes for the
matching components are deployed successfully.
Related links
Getting Started for Device Configuration Deployment
Creating a Device Configuration Template
Editing a Device Configuration Template
Deploying a Device Configuration Template (Bare Metal Deployment)
Viewing the Deployment Portal
To view the deployment portal, click Deployment → Deployment Portal.
Configuring the Deployment File Share
Before creating or deploying a configuration template from a device, you must configure the deployment file share on the server
running OpenManage Essentials. The deployment file share temporarily stores the configuration file that is used to retrieve and
apply the configuration settings on a target server or chassis.
To configure the deployment file share:
1. Perform one of the following:
• Click Settings → Deployment Settings.
• Click Deployment. In the Common Tasks pane, click File Share Settings.
• Click Deployment → Getting Started for Deployment → Configure Deployment File Share.
122
