2. In the Device Compliance pie-chart, click the Non licensed segment. The All Non licensed Devices window displays the
possible targets for server configuration management that do not have a license.
Related links
Deploying a Device Configuration Template (Bare Metal Deployment)
Deploying a Device Configuration Template (Stateless Deployment)
Setting Up Device Configuration Auto Deployment (Bare Metal Deployment)
Setting Up Device Configuration Auto Deployment (Stateless Deployment)
Configuring the Credentials and Device Configuration Inventory Schedule
Device Requirements for Deployment and Compliance Tasks
The following are the device requirements for device configuration deployment and configuration compliance tasks:
• For servers:
– Dell’s 12th or 13th generation of PowerEdge servers with the latest version of iDRAC7/8 and Lifecycle Controller firmware
installed.
– OpenManage Essentials — Server Configuration Management license installed on the iDRAC. This license is not the same
as the iDRAC license.
– iDRAC Enterprise or iDRAC Express license. This license is not the same as the OpenManage Essentials — Server
Configuration Management license.
• For chassis:
– PowerEdge M1000e with the latest version of CMC firmware installed.
– PowerEdge VRTX with the latest version of CMC firmware installed.
– PowerEdge FX2 or FX2s with the latest version of CMC firmware installed.
• For IOAs:
– Dell PowerEdge I/O Aggregator must be configured in one of the following operational modes:
* Standalone
* Virtual Link Trunk (VLT)
* Programmable MUX (PMUX)
NOTE: Compliance tasks are not supported for IOAs.
– For Dell OpenManage Essentials version 2.2, the I/O Aggregator must have firmware version 9.10.0.0 installed.
– For Dell OpenManage Essentials version 2.2.0.1, the I/O Aggregator must have either of the firmware versions 9.10.0.0,
9.10.0.1P10, 9.11.0.0 installed.
NOTE: For information on the supported iDRAC/Lifecycle Controller and CMC firmware versions, see the OpenManage
Essentials documentation at dell.com/OpenManageManuals.
Related links
Creating a Device Configuration Template From a Device Configuration File
Creating a Device Configuration Template From a Reference Device
Deploying a Device Configuration Template (Bare Metal Deployment)
Deploying a Device Configuration Template (Stateless Deployment)
Deploying a Network ISO Image
Setting Up Device Configuration Auto Deployment (Bare Metal Deployment)
Configuring the Credentials and Device Configuration Inventory Schedule
Viewing the Device Configuration Inventory
121
