Table 49. VLAN Configuration Task
Field Description
Task Name
Displays the name of the VLAN configuration task.
Selected IO Module Ports
Displays the IOA ports that you have selected to apply changes.
Grouped by: Fabric
Displays the attribute by which the currently displayed data is
grouped. By default, the VLAN configuration inventory is
grouped by Fabric.
Chassis Blade
Displays details of the blade servers that are installed in the
chassis.
Server Name
Displays host name of the blade server.
Service Tag
Displays the unique identifier assigned to the blade server.
Model
Displays the model name of the blade server.
Slot
Displays the slot where the server is installed.
Subslot
Displays the subslot of the server node.
NIC
Displays the Fully Qualified Device Descriptor (FQDD) of the
NIC.
NIC Port
Displays the NIC port to which the server is connected.
Chassis IOA
Displays details of the IOAs that are installed in the chassis.
IOA Name
Displays the name of the selected IOA.
IOA Model
Displays the model name of the selected IOA.
Fabric
Displays the fabric associated with a specific slot of the chassis.
The fabric is identified by a combination of the group name (A,
B, or C) and slot number (1 or 2).
Port
Displays the port assigned to the IOA.
Tagged VLAN(s)
Displays the list of tagged VLANs for the selected IOA.
Untagged VLAN
Displays the untagged VLAN for the selected IOA.
Set the Task Schedule
Run now
Select to run the configuration task immediately.
Set Schedule
Select to schedule a task at a required date and time.
Enter IOA Credentials for the task execution
User Name
Provide the fabric administrator user name required to run the
task.
111
