Dell NAS Appliance Support
The following table provides information about discovery and classification, availability of appliance node information, and alert
correlation for supported Dell NAS appliances.
Table 45. Dell NAS Appliance Support
Dell EqualLogic FS7500 with
FluidFS Version 1
Dell EqualLogic FS7500 with
FluidFS Version 3
Dell PowerVault MD NX3500 with
FuildFS Version 1
Discovery and
Classification
Support for discovery using both
the EqualLogic Group Manager IP
and management IP.
If discovered using the controller
IPs, it results in multiple entries.
Support for discovery using the
controller/node IPs.
If discovered using the EqualLogic
Group Manager IP, the device will
get classified under Dell EqualLogic
Group.
Support for discovery using both
the controller IPs.
If discovered using the PowerVault
MD Series array IP, the device is
classified as a PowerVault MD
Array device.
Appliance Node
Information
Displayed in the device inventory. Displayed in the device inventory. Displayed in the device inventory.
Alerts Alerts received from the controller
are not correlated to the device.
Alerts received from the
controller/node are correlated to
the device.
NOTE: It is highly
recommended to include all
controller/node IP addresses
in the discovery range
configuration while
discovering a NAS cluster
with FluidFS version 3.0.
This enables OpenManage
Essentials to properly
associate the SNMP alerts
received from various
participating controllers/
nodes with the discovered
cluster.
Some alerts received from the
device may be displayed as
Unknown.
OEM Device Support
Dell OEM devices (re-branded or de-branded Dell servers and Compellent S8000 iDRAC), when discovered, are classified under
OEM Devices in the device tree. Most of the functionality available to Dell servers, such as tasks, reports, and filters are also
applicable to Dell OEM servers. However, system update may not be possible if it is not supported by the OEM device module. For
more information on the supported protocols and features, see information on Dell servers/devices in Supported Devices Protocols
and Features Matrix.
OEM servers are always classified under the OEM Devices group in the device tree. They are not displayed under the Servers or
RAC group. If both the server and RAC of the OEM device are discovered, they are correlated and displayed as one device under
the OEM Devices group. Other OEM devices except servers and RAC are classified under the different server groups such as
Microsoft Virtualization Servers, VMware ESX servers, and so on, based on the classification criteria they satisfy.
NOTE: Dell OEM servers discovered using WMI protocol are classified under the Servers device group only when OMSA
is installed. OEM servers without OMSA are classified under the Unknown device group.
107
