The VLAN Configuration window displays the IOA ports that you modified.
NOTE: You can also modify the VLAN IDs in the VLAN Configuration window.
3. Type a unique name of the task.
NOTE: It is recommended that you enter a unique name for the task.
4. If required, select a schedule for the task.
5. Type the credentials of the IOA that have fabric administrator rights.
6. Click Finish.
The VLAN Configuration task is displayed in the Task Results tab. After the task is completed, OpenManage Essentials
automatically inventories the VLAN configuration of the IOAs on the chassis.
NOTE: While applying VLAN assignments to multiple ports, the VLAN configuration task may fail. The Task Results tab
displays the ports to which the VLAN assignments failed with a message stating that the task failed after multiple retries
or the server closed the network connection unexpectedly. In such a scenario, you can retry the VLAN configuration
after some time to the ports were not configured successfully.
NOTE: OpenManage Essentials uses the IOA CLI commands to configure the VLAN on the IOA. Configuring the VLAN on
the IOA is a time consuming and resource-intensive operation that may affect the performance of the IOA. To balance
the operations on the IOA, OpenManage Essentials runs the IOA CLI commands in a timely manner, ensuring that there
is sufficient time to configure the VLAN on the IOA. If the IOA is already running several operations, the VLAN
configuration task may either be prolonged or fail. If the VLAN configuration fails on some IOA ports, you can rerun the
VLAN configuration task on the corresponding IOAs.
Resetting all VLAN IDs
Before you begin, ensure that you have fabric administrator rights.
After you make changes to VLAN IDs, if you want to revert all the changes:
1. Click Reset All.
2. When you are requested to confirm, click Yes.
NOTE: The changes you made to the VLAN IDs are affected only in the OpenManage Essentials user interface.
Setting the Default VLAN ID Values
Before you begin, ensure that you have fabric administrator rights.
If you want to set the default VLAN IDs:
1. Select the IOA fabric port that you want to set to the default VLAN ID.
2. Click Set to default value.
The tagged VLAN column displays All VLANs and the untagged VLAN column displays 1.
NOTE: For tagged VLANs, the default value of All VLANs ranges from 2 to 4094. For untagged VLAN, the default
value is 1.
3. Click Apply.
4. Type a unique name of the task.
5. If required, select a schedule for the task.
6. Type the credentials of the IOA that have fabric administrator rights.
7. Click Finish.
The VLAN Configuration task is created in the Task Results tab. After the task is completed, OpenManage Essentials automatically
inventories the VLAN configuration of all IOAs in the chassis.
