Viewing the VLAN Configuration Inventory
To view the VLAN configuration inventory of a chassis:
1. Click Manage → Devices.
2. In the device tree, click Modular Systems.
3. Click PowerEdge M1000e or PowerEdge FX2 and then click the chassis CMC node.
4. On the right pane, click the VLAN Configuration tab.
The VLAN configuration inventory is displayed.
NOTE: If you are accessing the VLAN Configuration tab for the first time, click the refresh icon that is
displayed at the middle of the VLAN Configuration tab to display the configuration inventory.
NOTE: The VLAN configuration inventory that is displayed may not be up-to-date. To view the latest VLAN
configuration inventory, click the refresh icon
that is displayed at the top-right of the VLAN Configuration
tab.
NOTE: VLAN configuration inventory is not displayed in the following scenarios:
• The IOAs are not discovered or configured
• The IOA is not configured in either Standalone or Virtual Link Trunk (VLT) operational mode
Even though the VLAN configuration inventory is not displayed, OpenManage Essentials displays the IOA Name and
Model information if it is available. Otherwise a status message is displayed, indicating the reason for the non-availability
of the inventory information.
The following table describes the status messages that may be displayed.
Table 44. Viewing the VLAN Configuration Inventory
Status Description
Device not discovered The IOA is not discovered in OpenManage Essentials.
Slot is empty The chassis fabric slot is empty.
Firmware or Mode not supported The operational mode or firmware version of the IOA is not
supported.
Unable to retrieve data OpenManage Essentials is unable to retrieve the VLAN
configuration inventory from the IOA.
Unknown/Error An error occurred or the status is unknown.
Model not supported The IOA model is not supported.
Assigning VLAN IDs
Before you begin, ensure that you have IOA administrator rights.
To apply VLAN assignments:
1. On the VLAN Configuration tab, under Chassis IOA, type the VLAN IDs in the Tagged VLANs and Untagged VLAN columns
for the appropriate ports.
NOTE: The valid range for VLAN IDs are 1 to 4094. Use a comma (,) to separate VLAN IDs and use a hyphen (-) to
specify the ID range.
2. Click Apply.
