Support For PowerEdge FX Chassis Sleds
The sleds that can be installed in the PowerEdge FX2 and PowerEdge FX2s chassis may vary. The following are the types of sleds
and their support in OpenManage Essentials:
• Compute sleds — Require discovery and inventory for getting the inventory information and other functionality. Discovery and
classification of these sleds can be performed using OMSA (in-band) or iDRAC (out-of-band).
• Storage sleds — These sleds are not discoverable and are not displayed in the device tree, device summary, or any typical
locations for a device. The storage sled is displayed in the Chassis View and the storage sled inventory is displayed in the chassis
inventory page.
• Sleds with multiple compute nodes — An example of this type of sled is the PowerEdge FM120x4 sled which contains four
compute nodes. If the compute nodes of the sled are discovered, they are displayed in the device tree under: All Devices →
Modular Systems → PowerEdge FX → Chassis Group → Sled Group → Server Node. Each compute node is displayed under
the corresponding sled. The Sled Group name in the device tree can be edited if necessary.
NOTE: For in-band (without OMSA) discovery and monitoring of the PowerEdge FM120x4 sled, ensure that either
the WMI or SSH protocol is enabled and setup.
NOTE: The sleds installed in a PowerEdge FX chassis are sorted based on the device name and not on the slot number in
the device tree.
VLAN Configuration Management
The VLAN Configuration tab enables you to:
• View details of the blade server and IOA fabric interconnect such as the blade server NIC port, the associated IOA fabric port,
and the VLAN IDs.
NOTE: Even if there is no information available for the IOAs, the fabric status is shown as data in grid and values
such as Slot is empty and Firmware or Mode is not supported.
• Assign VLAN IDs to the IOAs within the chassis.
NOTE: If an already discovered IOA or server is moved from one chassis to another, removed from a chassis, or swapped
within the chassis, you must delete and rediscover the chassis, servers, and the corresponding IOAs. Otherwise, the
VLAN configuration inventory may display duplicate or incorrect data.
Requirements for VLAN Configuration Management
• VLAN configuration management is supported only for Dell PowerEdge M1000e and Dell PowerEdge FX2/FX2s
• The chassis and its components (blade servers and IOAs) must be discovered in OpenManage Essentials using the Guided
Wizard
• The IOAs must be configured in either the Standalone or Virtual Link Trunk (VLT) operational mode
• The minimum required firmware version is as follows:
– PowerEdge M1000e — CMC firmware version 5.1 or later.
– PowerEdge FX/FX2s — CMC firmware version 1.2 or later.
– PowerEdge M and FN IOA
* 9.10.0.0 supports Dell OpenManage Essentials version 2.2
* 9.10.0.0, 9.10.0.1P10, 9.11.0.0 supports Dell OpenManage Essentials version 2.2.0.1
NOTE: VLAN configuration management is not supported for the Dell PowerEdge FM120x4 sleds. Only the server-
chassis slot mapping is displayed in the VLAN Configuration tab for the PowerEdge FM120x4 sleds. The server name and
NIC port details are not displayed in the VLAN Configuration tab for the PowerEdge FM120x4 sleds.
104
