API Guide

Table 143. Attributes (continued)
Attribute name Description
Name Name of the job type.
Params
operationName Name of the Quick-Deploy operation.
deviceId Device ID indicates the Chassis ID.
rootCredential Root user password.
networkTypeV4 Indicates if the IPv4 is static or dynamic.
protocolTypeV4 Indicates whether IPv4 protocol is selected.
subnetMaskV4 IPv4 Subnetwork mask associated with the configuration.
Applicable when static IPv4 is selected.
gatewayV4 IPv4 gateway IP associated with the configuration. Applicable
when static IPv4 is selected.
networkTypeV6 Indicates if the IPv6 is static or dynamic.
protocolTypeV6 Indicates whether IPv6 protocol is selected.
prefixLength Used for IPv6 subnet mask. Applicable when static IPv6 is
selected.
gatewayV6 IPv6 gateway IP associated with the configuration. Applicable
when static IPv6 is selected.
SlotId=<slot_id> Indicates the slot where the settings are applied if slot
selected is True.
Example:
SlotSelected=true;SlotType=3000;IPV4Addres
s=10.27.0.1;IPV6Address=ax0
● SlotSelected=true or false. Indicates if the slot is selected
for applying Quick Deploy.
● SlotType = The type of slot.
● Sled type is 2000.
● IPV4Address = IPV4 address to be set at slot level.
● PV6Address = IPV6 address to be set at slot level.
366 APIs specific to OpenManage Enterprise - Modular Edition
