API Guide

Description Returns the role of a specific chassis domain.
● Part of MCM — LEAD or MEMBER
● Not part of MCM — STANDALONE
Privilege VIEW
HTTP response
codes
200
Example
Input:
Output:
{
"@odata.context": "$metadata#ManagementDomainService.Domain/$entity",
"@odata.id": "/api/ManagementDomainService/Domains(2714)",
"Id": 2714,
"DeviceId": 2664,
"Address": "fde1:53ba:e9a0:de14:1a66:daff:fe76:4ebc",
"Name": "cmc-LEAD123",
"Description": "Chassis-LEAD123",
"Identifier": "LEAD123",
"DomainTypeId": 4000,
"DomainTypeValue": "MSM",
"DomainRoleTypeId": 3000,
"DomainRoleTypeValue": "LEAD",
"Version": "VERSION",
"Port": "443",
"Local": true,
"GroupId": "4e361023-07cc-4b98-af3f-ba7c2ef2f5b9",
"GroupName": "DDD"
}
Table 126. Attributes
Attribute Description
Id Record ID.
DeviceId Device ID.
Address IP address.
Name Name of the chassis.
Description Description of the chassis.
Identifier Service Tag of the chassis.
DomainTypeId Information for internal programmatic use.
DomainTypeValue Information for internal programmatic use.
DomainRoleTypeId ID of the domain role. Possible value:
● 3000 — LEAD
● 3001 — MEMBER
● 3002 — STANDALONE
DomainRoleTypeValue Type of domain role. Possible values:
● LEAD
● MEMBER
● STANDALONE
Version Version of OME - Modular.
Local
● TRUE — Indicates that this domain is the local domain
where the API is executed.
APIs specific to OpenManage Enterprise - Modular Edition 297
