IntelTxt/inteltxt
Table 201. IntelTxt/inteltxt
Valid Arguments
• On systems prior to 12G: enable, disable
• On 12G and later systems: On, O
Description
Turns the Trusted Execution Technology on or o. To enable Intel TXT, VT must be
enabled, and the TPM must be enabled with pre-boot measurements and activated.
Example:
A:>syscfg --inteltxt=enable
inteltxt=enable
NOTE: To enable the Intel TXT option in a supported processor, make sure that
the:
• Virtualization technology in Processor setting is enabled.
• TPM module is installed and initialed as OK by BIOS.
• TPM security in System security is set to on with pre-boot measurements.
• User password is not set.
Applicable Systems All PowerEdge 11G and later systems with Intel processors.
NmiButton/nmibutton
Table 202. NmiButton/nmibutton
Valid Arguments
• On systems prior to 12G: enable, disable
• On 12G and later systems: Enabled, Disabled
Description
Enables or disables the Non-Maskable Interrupt (NMI) button on the front panel. The
NMI button can be used to alert the operating system in certain cases.
NOTE: This option congures Baseboard Management Controller (BMC) and
Remote Access Controller (RAC) settings.
Example:
A:>syscfg --nmibutton=enable
nmibutton=enable
Applicable Systems PowerEdge 11G and later systems
PasswordStatus/pwdlock
Table 203. PasswordStatus/pwdlock
Valid Arguments
• On systems prior to 12G: lock, unlock
• On 12G and later systems: Locked, Unlocked
Description
Locks the system password. To prevent the system password from being modied, set
this option to lockedand enable setup password. This eld also prevents the system
password from being disabled by the user while the system boots.
Example:
A:>syscfg --pwdlock=lock
pwdlock=lock
93
