NOTE: The value of
n
in ProcnControlledTurbo can be 1–4.
Example:
A:>syscfg --Proc1ControlledTurbo=Disabled
ProcCongTdp
Table 119. ProcCongTdp
Valid Arguments
• On systems prior to Dell’s 13th generation PowerEdge systems: NA
• On Dell’s 13th generation PowerEdge and later systems: Nominal, Level1, Level2
Description
Congures the Thermal Design Power (TDP).
Example:
A:>syscfg --ProcConfigTdp=Nominal
ProcConfigTdp=Nominal
ProcX2Apic
Table 120. ProcX2Apic
Valid Arguments
• On systems prior to Dell’s 12th generation PowerEdge systems: NA
• On Dell’s 12th generation PowerEdge and later systems: Enabled, Disabled
Description
Enables or disables the x2APIC mode.
Example:
A:>syscfg --ProcX2Apic=Enabled
ProcX2Apic=Enabled
Applicable Systems Dell’s 12th generation PowerEdge and later systems
SATA Settings
You can manage the BIOS SATA settings using the options in this group.
EmbSata / embsataraid
Table 121. EmbSata / embsataraid
Valid Arguments
• On systems prior to Dell’s 12th generation PowerEdge systems: o, combined, ata,
ahci, raid, qdma
• On Dell’s 12th generation PowerEdge and later systems: O, AtaMode, RaidMode,
AhciMode
Description
Congures an embedded SATA RAID controller. This option can be replicated.
• o /O — disables the embedded SATA RAID controller.
• combined— sets the SATA RAID controller to combined mode.
• ata/ AtaMode— sets SATA RAID controller to ATA mode.
• ahci/ AhciMode— sets ATA RAID controller to ahci mode.
• raid/RaidMode — sets SATA RAID controller to RAID mode.
• qdma — sets the SATA RAID controller to support ATAPI devices at transfer rates
much higher than PIO. A device driver must be installed on your system to use the
QDMA mode.
69
