• On 12G and later systems: read-only
Description
Displays the amount of memory in the corresponding processor cache.
Example:
A:>syscfg --Proc4L3Cache
Applicable Systems PowerEdge 12G and later systems.
Proc4NumCores*
Table 106. Proc4NumCores*
Valid Arguments
• On systems prior to 12G: NA
• On 12G and later systems: read-only
Description
Displays the number of cores in the processor package.
Example:
A:>syscfg --Proc4NumCores
Applicable Systems PowerEdge 12G and later systems.
Proc64bit*
Table 107. Proc64bit
Valid Arguments
• On systems prior to Dell’s 12th generation PowerEdge systems: NA
• On Dell’s 12th generation PowerEdge and later systems: Read-only
Description
Species if the installed processor supports 64-bit extensions or not.
Example:
A:>syscfg --Proc64bit
Applicable Systems On Dell’s 12th generation PowerEdge systems and later systems.
ProcAdjCacheLine/adjcacheprefetch
Table 108. ProcAdjCacheLine / adjcacheprefetch
Valid Arguments
• On systems prior to Dell’s 12th generation PowerEdge systems: Enable, Disable
• On Dell’s 12th generation PowerEdge and later systems: Enabled, Disabled
Description
When set to Enabled (default), the system is optimized for applications that require
high utilization of sequential memory access. When set to Disabled, the system is
optimized for applications that require high utilization of random memory access.
Example:
A:>syscfg --adjcacheprefetch=enable
adjcacheprefetch=enable
Applicable Systems All PowerEdge systems.
65
