Example:
A:>syscfg --DynamicCoreAllocation=Enabled
DynamicCoreAllocation=Enabled
Applicable Systems PowerEdge 12G and later systems
MemOpMode/memoperatingmode
Table 59. MemOpMode/memoperatingmode
Valid Arguments
• On systems prior to 12G: optimizer, mirror, advancedecc
• On 12G and later systems: OptimizerMode, SpareMode, MirrorMode, AdvEccMode,
SpareWithAdvEccMode
Description
Selects the memory operating mode. This feature is active only if a valid memory
conguration is detected. When OptimizerMode is enabled, the DRAM controllers
operate independently in 64-bit mode and provide optimized memory performance.
When MirrorMode is enabled, only half of the installed memory is reported as
available to the operating system. When
AdvECCMode is enabled, the two DRAM
controllers are combined in 128-bit mode to provide optimized reliability. Memory that
cannot be teamed by the controllers is not reported to the operating system. When
SpareMode is enabled, the memory size reported to the operating system does not
include the spare portion.
Example:
A:>syscfg --memoperatingmode=optimizer
memoperatingmode=optimizer
Applicable Systems PowerEdge 11G and later systems
MemOpVoltage/-dimmvoltage
Table 60. MemOpVoltage/-dimmvoltage
Valid Arguments
• On systems prior to 12G: auto, 1.5
• On 12G and later systems: AutoVolt, Volt15V
Description
Sets the DIMM voltage selection. When set to AutoVolt(default value), the system
automatically sets the voltage to the optimal setting based upon the DIMM capability
and the installed DIMM population. This option also enables setting the system DIMM
voltage to a higher (1.5V) setting if the DIMMs support multiple voltages and have been
set to a lower voltage.
NOTE: Volt15V represents 1.5 Volt.
Example:
A:>syscfg --dimmvoltage=auto
dimmvoltage=auto
Applicable Systems PowerEdge 12G and later systems.
MemTest/memtest
Table 61. MemTest/memtest
Valid Arguments
• On systems prior to 12G: enable, disable
51
