Example:
A:>syscfg --Usb3Setting=Auto
Usb3Setting=Auto
Applicable Systems
All systems prior to PowerEdge 13G systems
CurrentEmbVideoState
Table 49. CurrentEmbVideoState
Valid Arguments
• On systems prior to 12G: NA
• On 12G and later systems: read-only
Description
Displays the current state of the Embedded Video Controller.
Example:
A:>syscfg --CurrentEmbVideoState
CurrentEmbVideoState=
xxx
Applicable Systems PowerEdge 12G and later systems
InternalSdCardPrimaryCard
Table 50. InternalSdCardPrimaryCard
Valid Arguments
• On systems prior to 13G: NA
• On 13G and later systems: SdCard1, SdCard2
Description
Sets an internal SD card as the primary SD card.
A:>syscfg --InternalSdCardPrimaryCard=SdCard1
InternalSdCardPrimaryCard=SdCard1
Network Settings
You can manage the system network settings using the options in this group.
PxeDev
n
EnDis
Table 51. PxeDev
n
EnDis
Valid Arguments
• On systems prior to 12G: NA
• On 12G and later systems: Enabled, Disabled
Description
Enables or disables the Preboot Execution Environment (PXE) device. When enabled, a
Unied Extensible Firmware Interface (UEFI) boot option is created for the PXE device.
NOTE: The value of n in PxeDevnEnDis can be 1–4.
Example:
A:>syscfg --PxeDev1EnDis=Enabled
PxeDev1EnDis=Enabled
Applicable Systems PowerEdge 12G and later systems
48
