Example:
A:>syscfg --SetLegacyHddOrderFqdd1=xxxx,yyy,zzzz
SetLegacyHddOrderFqdd1=xxxx,yyy,zzzz
Applicable Systems PowerEdge 13G and later systems
Integrated Devices
You can use the options in this group to manage the integrated devices such as internal NIC and integrated USB.
EmbNic1/embnic1
Table 27. EmbNic1/embnic1
Valid Arguments
• On systems prior to 12G: on, o, onnopxe, onwithiscsi
• On 12G and later systems: Enabled, EnabledPxe, EnablediScsi, Disabled
Description
Turns the rst embedded NIC on with PXE on, o, or on without PXE enabled. This
option is only valid for supported systems that have a NIC. If the NIC is enabled without
PXE, it is not found in the boot order. If the NIC is turned on with PXE, it is placed at
the end of the boot order. The onnopxe argument is not supported on all systems.
The onwithiscsi argument enables the embedded NIC to boot from the iSCSI server.
The embnic1 option can be replicated.
Example:
A:>syscfg --embnic1=onnopxe
embnic1=onnopxe
Applicable Systems All PowerEdge systems
EmbNic1Nic2/embnic1nic2
Table 28. EmbNic1Nic2/embnic1nic2
Valid Arguments
• On systems prior to 12G: enable, disable
• On 12G and later systems: Enabled, Disabled, DisabledOs
Description
Enables or disables the operating system interface of the rst and second embedded
NIC controllers.
Example:
A:>syscfg --embnic1nic2=enable
--embnic1nic2=enable
Applicable Systems PowerEdge 11G and later systems
EmbNic2/embnic2
Table 29. EmbNic2/embnic2
Valid Arguments
• On systems prior to 12G: on, o, onnopxe, onwithiscsi
• On 12G and later systems: Enabled, EnabledPxe, EnablediScsi, Disabled
Description
Turns the second embedded NIC on with PXE on, o, or on without PXE enabled. This
option is only valid for supported systems that have a NIC. If the NIC is enabled without
41
