– The BIOS version or hardware feature set.
– A missing or expired license. The system displays an error message if the required license is not found. For more information,
see Dell License Manager on dell.com/support/manuals.
• Some of the options are followed by an asterisk. The asterisk is not part of the command syntax. Such options are used for
reporting purposes only. These commands do not accept any suboptions or arguments. The values associated with these
commands are reported by the BIOS. You cannot modify these values.
SYSCFG BIOS commands
SYSCFG BIOS equivalent RACADM commands are listed:
For more information on RACADM commands, see the RACADM Command Line Reference Guide available at dell.com/
openmanagemanuals.com.
Table 19. BIOS options with equivalent RACADM options
Group Option on 12G and Later
systems
Option on Systems
Prior to 12G Systems
Equivalent RACADM Option
BIOS Option Settings --BootSeq --bootseq BIOS.BiosBootSettings.BootSeq
--HddSeq --devseq BIOS.BiosBootSettings.HddSeq
Boot Settings --BootMode --bootmode BIOS.BiosBootSettings.BootMode
--BootSeqRetry --bootseqretry BIOS.BiosBootSettings.BootSeqRetry
--HddFailover
NOTE: The option is
not supported on
12G systems.
--hddfailover BIOS.BiosBootSettings.HddFailover
--SetBootOrderFqddn
NOTE: The option is
supported only on
13G and later
systems.
N/A BIOS.BiosBootSettings.SetBootOrderFqddn
--
SetLegacyHddOrderFqdd
n
NOTE: The option is
supported only on
13G and later
systems.
N/A BIOS.BiosBootSettings.SetLegacyHddOrderFqd
d
Integrated Devices --EmbVideo --embvideoctrl BIOS.IntegratedDevices.EmbVideo
--IoatEngine --ioat BIOS.IntegratedDevices.IoatEngine
--IntegratedNetwork1 N/A BIOS.IntegratedDevices.IntegratedNetwork1
--IntegratedNetwork2 N/A BIOS.IntegratedDevices.IntegratedNetwork2
--IntegratedRaid --integratedraid BIOS.IntegratedDevices.IntegratedRaid
--IntegratedSas --integratedsas BIOS.IntegratedDevices.IntegratedSas
--InternalSdCard --embsdcard BIOS.IntegratedDevices.InternalSdCard
