Error Code Message
1028 Cannot increase the virtual disk size due to lack of free space or due
to the presence of partial virtual disks on the same set of array disks.
1029 The percentage value of virtual disk size must be in the range 1-100.
1030 Error! Cannot discard the preserved cache. Use '-force' option to
discard the cache.
1031 Cannot create a new virtual disk because preserved cache is present on
the controller. To clear the cache, either import the related virtual
disks or discard the cache.
1032 Unsupported RAID value. The expand virtual disk size operation is
allowed only on RAID-0, RAID-1, RAID-5, and RAID-6.
1033 Unsupported file type. Supported file types are .ini, .log, and .txt.
RACADM Firmware Error Codes And Messages
Table below lists RACADM rmware error codes and messages.
Table 357. RACADM Firmware Error Codes and Messages
Error Code Message
1 UNKNOWN COMMAND.
2 OUTPUT ERROR
3 TOO FEW ARGUMENTS
4 UNKNOWN PARAMETER
5 CAN'T LOCK RESOURCE
6 RESOURCE LOCKED
7 USER NOT IN DATABASE
8 WRONG PASSWORD
9 LOGIN INCORRECT
10 NOT ACCESSIBLE VIA TELNET CONNECTION
11 ACCESS DENIED
12 INVALID ARGUMENT
13 INVALID GROUP NAME
14 USER DATABASE FULL
15 CAN'T CHANGE FACTORY DEFAULT
16 USER ALREADY IN DATABASE
17 CLOSING TELNET CONNECTION
18 USER DATABASE NOT INITIALIZED
19 INVALID COMMAND SHELL CALL
