Error Code Message
array disks, RAID 10 requires at least 4 array disks and RAID 50
requires at least 6 array disks.
221 No free array disks found!
222 No global failover disks found!
223 One or more array disks selected for the virtual disk has foreign
configuration.
224 Error in opening the file.
225 SAS 5/IR, SAS 6/IR, H200 and SW RAID requires atleast two physical disks
to create RAID 0 or RAID 1.
226 No Foreign configuration present in the controller.
227 The virtual disk cannot be created on the physical disks you selected.
Possible reasons include:unsupported mix of SAS and SATA protocol type
disks, unsupported mix of SSD and HDD media disks.
228 Unsupported array disks selected for VD creation.
229 Setting stripe size is not supported in this controller.
230 Invalid VirtualDisk(VD) name specified. VD name can have alphanumeric
characters [A-Z,a-z,0-9,_,-] only. Also, VD name size must be less than
or equal to 15 characters
231 Error occurred while setting virtual disk as boot disk.
232 Error occurred while setting name for virtual disk.
233 Couldn't get boot virtual disk.
234 PCIe Link Speed could not be set for the RAID controller. Please check
if the controller has the capability to set/change its PCIe link speed.
235 PCIe Link Speed can be set to either 2 or 3 i.e. PCIe Generation 2.0 or
3.0.
236 PCIe Link Speed could not be retrieved for this RAID controller.Please
check if the controller has the PCIe link speed capability.
237 Please reset the controller before doing any further operation.
238 Boot Mode can be set to 0 (BIOS stop on error), 1 (BIOS continue on
error), 2 (Headless continue on error)
239 Boot Mode could not be set for the RAID controller.
240 Enable Auto Import can be set to 0 (No) or 1 (Yes).
241 Cannot discard the preserved cache because a foreign configuration is
present on the controller. Use '-ignoreconfig' or '-igncfg' to discard
the cache.
1000 Enable Auto Import property could not be set for the RAID controller.
1001 Invalid array disk list.
1002 Source or destination disk is in invalid state. Make sure that the
source disk is in online state, destination disk is in ready state, and
