Error Code Message
173 Cluster Services (MSCS) is running. Deleting a virtual disk that
contains a cluster resource can result in unpredictable errors or system
hangs (quorum disk). You should shut down cluster services before
deleting cluster resources. Are you sure you want to proceed?
174 Cannot perform Create Virtual Disk or Delete Virtual Disk while the
other server in a cluster is online. Please shut one of the servers down
and retry the operation.
176 Invalid array disks or failover drives selected for reconfigure/create
operation. Please make sure that all array disks and failover drives
associated with the virtual disk are selected.
177 The maximum number of partitions have already been created on one of the
selected array disk(s). Each array disk can hold portions (partitions)
of up to 10 virtual disks. This virtual disk cannot be created because
one or more array disk(s) have reached the partition limit.
178 The virtual disk is in use. Please close any applications that use the
virtual disk and unmount any file systems that reside on the virtual
disk.
179 The firmware version is not supported. Please update the firmware from
http://support.dell.com.
180 The specified device does not have enough free space to be used as
failover space for the specified virtual disk.
181 The operation failed. Please rescan the controller and retry the
operation.
182 The operation cannot be performed while a task is running on the
specified virtual disk.
183 The specified virtual disk has no dead disk segments.
184 The operation cannot be performed at this time. The firmware can
recondition a battery that has a Degraded or Power Low state. The
firmware will not recondition a battery that is functioning normally or
that has a Ready, Failed or Missing state.
185 The version of the controller firmware installed on your system does not
support this operation.
186 There are no disks of the correct type available to be assigned as a hot
spare.
187 There are no disks of sufficient size available to be assigned as a hot
spare.
188 There are no disks of the correct type and sufficient size available to
be assigned as a hot spare.
189 The Create Virtual Disk task was successful but the operating system may
not be aware of the new virtual disk.
191 The import of foreign configurations is complete. Some configurations
could not be imported.
205
