Error Code Message
166 Invalid IPv6 configuration. Attempt to set DNS server address manually
while DNS address source is set to auto.
167 Invalid IPv6 configuration. Attempt to set IPv6 address manually while
IPv6 address source is set to auto.
168 Invalid IPv6 configuration. Attempting to apply IPv6 configuration
without loading IPv6 stack.
169 Invalid IPv4 configuration. Attempting to apply IPv4 configuration with
IPv4 disabled.
170 Invalid IPv6 configuration. Ipv6 address cannot be specified without
specifying prefix-length.
171 Invalid IPv6 configuration. dnssrcv6 cannot be set to auto when ipsrcv6
is set to manual.
172 Error while executing IPMI Set command.
173 Error while executing IPMI Get command.
174 Error during Trap Alert.
175 Unspecified error.
176 Getting LCD settings failed.
177 Invalid configuration. Attempting to set cap when capenable is set to
disable.
178 Invalid configuration. Attempting to set cap when hardware does not
support setting.
179 Invalid Configuration Option.
180 Cannot execute command. Parameter is illegal because command sub-
function has been disabled or is unavailable.
181 Failed to report the removable flash media redundancy status.
182 Failed to report the Internal SD Module status.
183 Error locating the Virtual Media Key on the Modular system.
184 Error in setting the redundancy option for the Internal SD Modules.
185 Error in retrieving the redundancy option for the Internal SD Modules.
186 Error in setting the redundancy option on Modular systems for the
Internal SD Modules.
187 Error in retrieving the vFlash option.
188 Error in setting the vFlash option.
189 The set operation failed due to dependency.
190 The set operation failed because attribute is forced to a value.
191 Cannot disable this OrderedList’s entries.
192 The set operation failed because system is busy now . Try again later.
