Error Code Message
48 Command response could not be provided. SDR Repository in update mode.
49 Cannot execute command, SEL erase in progress.
50 Attempt to set the 'set in progress' value when not in the 'set in
complete' state.
51 The SOL character ’accumulate interval’ is invalid.
52 The SOL character ’send threshold’ is invalid.
53 The SOL ’retry interval’ is invalid.
54 Command completed successfully.
55 Time-out while processing command. Response unavailable.
56 Unspecified error.
57 The password may only contain printable ASCII characters.
58 Username cannot exceed 16 characters.
59 Invalid VLANID value. Enter in ’dddd’ format.
60 Attempt to write read-only parameter.
61 BMC is busy.
62 Response data did not return successfully.
63 BMC time out error.
64 Option requires an argument.
65 The asset tag for this system is not available.
66 The asset tag cannot be more than 10 characters long.
67 The required BIOS interfaces cannot be found on this system.
68 The BIOS version information is not available.
69 There is not enough free system memory to complete the BIOS update.
70 The BIOS update file version is a different version class (A00, X00)
than the current system BIOS. Use the --force option to use this BIOS
image.
71 The BIOS update file version is older than the current system bios. Use
the --force option to use this BIOS image.
72 The BIOS update file version is identical to the current system bios.
Use the --force option to use this BIOS image.
73 The sequence list must be a comma-separated numerical list of valid
unique boot device numbers (ex: 2, 1, 3).
74 The sequence list must be a comma-separated list of valid unique device
names (ex: nic.emb.1, hdd.emb.1) or a comma-separated numerical list of
valid unique boot device numbers (ex: 2, 1, 3).
75 There was an error setting the sequence.
76 The list is not formatted correctly. See the help for more details.
