Setting And Displaying The PCIe Link Speed
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for setting and displaying the Peripheral
Component Interconnect Express (PCIe) link speed of the controller.
Table 344. Setting and Displaying the PCIe Link Speed
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
--ctrl -c=id -
ac=spciels -
spd=<2 | 3>
or
controller
controllerid=id
action=setpcielin
kspeed speed=<2 |
3>
NA NA
Sets the PCIe link speed of the controller to PCIe
Generation 2 or 3.
NOTE: Reboot the system to apply the
setting.
Example:
A:>raidcfg -ctrl -c=2 -ac=spciels -
spd=2
RAIDCFG Command successful!
--ctrl -c=id -
ac=gpciels
or
controller
controllerid=id
action=getpcielin
kspeed
NA NA
Displays the PCIe link speed of the controller.
Example:
A:>raidcfg -ctrl -c=2 -ac=gpciels
RAIDCFG Command successful!
Supported Controllers And Firmware Versions For PCIe Link Speed
The following table lists the controllers and minimum supported rmware versions for PCIe link speed.
Table 345. Supported Controllers And Firmware Versions For PCIe Link Speed
Controllers Component Minimum Supported Versions
PERC H710 H710 Adapter 21.2.0-0007
H710 Mini Monolithic 21.2.0-0007
PERC H710P H710P Adapter 21.2.0-0007
H710P Mini Monolithic 21.2.0-0007
PERC H810 H810 Adapter 21.2.0-0007
Setting Boot Mode
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for setting the boot mode of the controller.
Table 346. Setting Boot mode
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
-ctrl -c=id -
ac=sbm —bm=<0|1|
2> or controller
NA NA
Sets the boot mode of the controller to any of the
following during the system start or reboot:
• Stop on error (0)
181
