Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
controller
controllerid=id
action=discardPre
servedCache —
force
Example:
A:>raidcfg -ctrl -c=2 -ac=dpc -
force
RAIDCFG Command successful!
--ctrl -c=id -
ac=dpc -force -
igncfg
or
controller
controllerid=id
action=discardPre
servedCache —
force -
ignoreconfig
NA NA
Discards the preserved cache on the controller
ignoring the foreign conguration.
Example:
A:>raidcfg -ctrl -c=2 -ac=dpc -
force -igncfg
RAIDCFG Command successful!
Initializing Virtual Disks
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for initializing selected virtual disks.
Table 341. Initializing Virtual Disks
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
-vd -c=id -vd=id
-ac=fi or vdisk
controllerid=id
vdisk=id
action=fastinit
NA NA
Initializes the selected virtual disk in the selected
controller with the fastinit command. This feature is
supported on PERC 5 and later controllers and is
not supported on SAS controllers.
Using the fastinit command on unsupported
controllers returns an error.
Example:
A:>raidcfg -vd -c=2 -vd=2 -ac=fi
-vd -c=id -vd=id
-ac=sli or vdisk
controllerid=id
vdisk=id
action=slowinit
NA NA
Initializes the selected virtual disk in the selected
controller with the slowinit command. This feature
is supported on PERC 5 and later controllers and is
not supported on SAS controllers. Using the
slowinit command on unsupported controllers
returns an error.
Example:
A:>raidcfg -vd -c=2 -vd=2 -ac=sli
-vd -c=id -vd=id
-ac=ci or vdisk
controllerid=id
vdisk=id
action=cancelinit
NA NA
Cancels the initialization of the virtual disk with the
cancelinit command. This feature is supported on
PERC 5 and later controllers and is not supported
on SAS controllers. Using the cancelinit command
on unsupported controllers returns an error..
Example:
A:>raidcfg -vd -c=2 -vd=2 -ac=ci
179
