Table 336. Conguring Physical Disk State
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
-ad -ac=online -
ad|-pd=
ch:targ:encl -
c=id
or
adisk
action=online
adisk|
pdisk=channel:tar
get:enclosure
controllerid=id
NA NA
Sets the array disk state to online.
Example:
A:>raidcfg -ad -ac=online -ad=0:1 -
c=2
-ad -ac=offline -
ad|-pd=
ch:targ:encl -
c=id
or
adisk
action=offline
adisk|
pdisk=channel:tar
get:enclosure
controllerid=id
NA NA
Cancels the rebuild of the physical disk associated
with a specied virtual disk.
Example:
A:>raidcfg -ad -ac=offline -ad=0:1
-c=2
Replacing Physical Disk Of A Virtual Disk
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for replacing the physical disk of a virtual disk
with a ready state disk.
Table 337. Replacing Physical Disk Of A Virtual Disk
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
-vd -ac=replacepd
-vd=id
ch:targ:encl -
c=id
or
vdisk
action=replacepdi
sk adisk|
pdisk=channel:tar
get:enclosure
controllerid=id
NA NA
Replaces the physical disk of a virtual disk by a
ready state disk, whose size is greater than or equal
to the size of the physical disk.
Example:
A:>raidcfg -vd -ac=replacepd -vd=2
-c=2 -src=0:1 -dest=0:1
Consistency check for virtual disk
The following table lists the RAIDCFG options, parameters, and predened arguments for a consistency check for a virtual disk.
