Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
get:enclosure
controllerid=id
-vd -ac=crbd -
ad|-pd=
ch:targ:encl -
c=id
or
vdisk
action=cancelrebu
ild adisk|
pdisk=channel:tar
get:enclosure
controllerid=id
NA NA
Cancels the rebuild of the physical disk associated
with a specied virtual disk.
Example:
A:>raidcfg -vd -ac=crbd -ad=0:1 -
c=2
Conguring Array Disk As RAID
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for conguring the array disk as RAID.
Table 335. Conguring Array Disk as RAID
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
-ad -ac=ctr -ad|-
pd= ch:targ:encl
-c=id
or
vdisk
action=converttor
aid adisk|
pdisk=channel:tar
get:enclosure
controllerid=id
NA NA
Congures the array disk as RAID.
Example:
A:>raidcfg -ad -ac=ctr -ad=0:1 -c=2
-ad -ac=ctnr -
ad|-pd=
ch:targ:encl -
c=id
or
vdisk
action=convertton
onraid adisk|
pdisk=channel:tar
get:enclosure
controllerid=id
NA NA
Congures the array disk as JBOD.
Example:
A:>raidcfg -ad -ac=ctnr -ad=0:1 -
c=2
Conguring Physical Disk State
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for conguring the physical disk state to
online or oine.
CAUTION: Setting a physical disk online or oine may result in data loss. Either complete an automatic rebuild of the
physical disk or initiate a consistency check of the virtual disk after an online task completes.
176
