Function Call Description
Example:
A:>raidcfg -se -envn=ADISKS -envc=getadisks -c=2
ADISKS=0:0:1,0:1:1,0:2:1
RAIDCFG Command successful!
getfreeadiskcount
Returns the number of free array disks found in the specied controller.
Example:
A:>raidcfg -se -envn=FREEADISKCOUNT -envc=
getfreeadiskcount -c=2
FREEADISKCOUNT=2
RAIDCFG Command successful!
getfreeadisksize
Returns the total size of the free array disks in megabytes.
Example:
A:>raidcfg -se -envn=FREEADISKSIZE -envc=
getfreeadisksize -c=2
FREEADISKSIZE=15346
RAIDCFG Command successful!
gethotspares
Returns the global hot spares (global failover disks) found on the specied controller.
Example:
A:>raidcfg -se -envn=HOTSPARES -envc=
gethotspares -c=2
HOTSPARES=1:8:1,1:9:1
RAIDCFG Command successful!
getfreeadisks
Returns the free array disks.
A:>raidcfg -se -envn=GETFREEADISKS -envc=
getfreeadisks -c=2
GETFREEADISKS=0:3:1,0:4:1
RAIDCFG Command successful!
getadiskcount
Returns the total number of array disks.
A:>raidcfg -se -envn=GETADISKCOUNT -envc=
getadiskcount -c=2
GETADISKCOUNT=1
RAIDCFG Command successful!
RAID Replication Options
The following table lists the RAID replication options.
