Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
or
vdisk
action=deletevdis
k controllerid=id
combination is mandatory. The second -vd option
is optional and can be added to the command line
in any order after the mandatory option.
Example:
A:>raidcfg -vd -ac=dvd -c=2 -vd=0
RAIDCFG Command successful!
NOTE: When virtual disks are created, the RAID controller starts the background initialization operation. Virtual disks
cannot be deleted until this operation completes.
NOTE: If the raid.ini le contains the [Reset] section, then the RAIDCFG utility removes all the hot spares (dedicated and
global) and virtual disks on the specied RAID controllers in the system.
Increasing Virtual Disk Size
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for increasing the virtual disk size of the
controller.
Table 320. Increasing Virtual Disk Size
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
-vd -c=id -
vd=vdid -ac=evs -
szinper=% or vdisk
controllerid=id
vdisk=vdid
action=expandvdsi
ze sizeinpercent=
%
NA NA
Increases the size of the virtual disk by the
specied percentage.
Example:
A:>raidcfg -vd -c=2 -vd=2 -ac=evs -
szinper=25
Setting A Virtual Disk As Bootable Virtual Disk
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for setting a virtual disk as a bootable virtual
disk.
Table 321. Setting A Virtual Disk As Bootable Virtual Disk
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
-vd -ac=sbf -
c=id or vdisk
action=
setbootflag
controllerid= id
-vd or vdisk
<valid virtual
disk ID number>
Sets the specied virtual disk as bootable virtual
disk on the specied controller.
Example:
A:>raidcfg -vd -ac=sbf -c=2 -vd=0
RAIDCFG Command successful!
Blinking And Unblinking Virtual Disks
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for blinking or unblinking a physical disk
associated with a virtual disk.
167
