Mandatory Options
and Arguments
Optional Parameters Valid Parameters/
Arguments
Description
Vendor: DELL (tm)
Model: ST3450757SS
Protocol: SAS
Media: HDD
MedSpeed: 6144 Mbps
CapSpeed: 6144 Mbps
Certified: YES
Supported: YES
Location: 0:0:1
Size: 428672 MB (418 GB)
Avail: 0 MB
PowerState: Spun Up
SMARTState: No Error
DiskState: Online
Encryption Capable: Yes
Secured: No
Sector Size: 512B
T10 Protection Info Capable: No
RAIDCFG Command successful!
-ad -c=id or adisk
controllerid=id
-ad= ch:targ,ch:t
arg,... adisk=
channel:tar get,
channel:tar
get,...
Displays information about the specied array disk.
This option combination is mandatory.
Example:
A:>raidcfg -ad -c=4 -ad=
0:0:1
****** Physical Drive ******
Vendor: DELL(tm)
Model: ST3450757SS
Protocol: SAS
Media: HDD
MegSpeed: 6144 Mbps
CapSpeed: 6144 Mbps
Certified: YES
Supported: YES
Location: 0:0:1
Size: 428672 MB (418 GB)
Avail: 0 MB
PowerState: Spun Up
SMARTState: No Error
DiskState: Online
Encryption Capable: Yes
Secured: No
Sector Size: 512 MB
T10 Protection Info Capable: No
RAIDCFG Command successful!
Blinking And Unblinking Array Disks
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for blinking and unblinking array disks (hard
drives).
NOTE: You can also use pdisk or -pd instead of adisk or -ad to specify an array disk.
