Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
controller has a battery. If the controller does
not have a battery and force write-back
caching is used, data loss may occur in the
event of a power failure
NOTE: The -wpoption is optional and can be
added to the command line in any order
after the mandatory option combination.
For SCSI controllers, the value of LUN should
always be 0.
For SAS controllers, the value of enclosure can be
non-zero, in which case you must specify values for
channel, target, and enclosure.
-sf or secureflag
0, 1
Creates a secured virtual disk on controllers with
encryption capability and encryption key.
Example:
A:>raidcfg -ctrl -ac=cvd
-c=2
-ad=1:4,1:8 -sf=1
RAIDCFG Command successful!
Enumerating Array Disks
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for enumerating array disks (hard-drives).
NOTE: You can also use pdisk or -pd instead of adisk or -ad to specify an array disk.
Table 316. Enumerating Array Disks (Hard Drives)
Mandatory Options
and Arguments
Optional Parameters Valid Parameters/
Arguments
Description
-ad -c=id or adisk
controllerid=id
NA NA
Lists all the array disks attached to the specied
RAID controller. This option combination is
mandatory.
NOTE: The following example displays the
output of a Series 7 controller.
NOTE: The software controller does not
display the NegSpeed, CapSpeed,
Certified and Supported parameters.
Example:
A:>raidcfg -ad -c=2
Controller: PERC H710P Adapter
****** Physical Drive ******
Vendor: DELL(tm)
Model: ST3300657SS
Protocol: SAS
Media: HDD
NegSpeed: 6144 Mbps
CapSpeed: 6144 Mbps
Certified: YES
162
