Deployment Guide

Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
lun,
channel:target:
lun,...
[or
channel:target:
enclosure,...]
For SAS controllers, the value of enclosure can be
non-zero, in which case you must specify values for
channel, target, and enclosure.
-ctrl -ac=cvd -
c=id -ad=
ch:targ,ch:targ ,
... [or
ch:targ:encl,...]
or
controller
action=
createvdisk
controllerid= id
adisk=
channel:target:
lun,
channel:target:
lun,... [or
channel:target:
enclosure,..
-str or strict <number>
Strict (-str parameter) is the percentage of
expected array disk utilization.
Example:
A:> raidcfg -ctrl -ac=
cvd -c=0 -ad=0:0,0:1 -
r=1 -str=20
If the unused portion of an array disk is greater
than the mentioned percentage, raidcfg aborts.
For SCSI controllers, the value of LUN should
always be 0.
For SAS controllers, the value of enclosure can be
non-zero, in which case you must specify values for
channel, target, and enclosure.
-ctrl -ac=cvd -
c=id -ad=
ch:targ,ch:targ,
... [or
ch:targ:encl,...]
or
controller
action=
createvdisk
controllerid= id
adisk=
channel:target:
lun,...
channel:target:
lun,... [or
channel:target:
enclosure,...]
-sz or -size <number>
Sets the maximum size of the virtual disk in MB or
GB. A valid argument is a number representing the
maximum size for the virtual disk. The -szoption is
optional and can be the added to the command line
in any order after the mandatory option
combination.
The minimum virtual disk size that you can create
for various controllers is as follows:
• For PERC 5 controllers:
– RAID 0: 100 MB
– RAID 1: 100 MB
– RAID 5: 100 MB
• For PERC 6 controllers:
– RAID 0: 100 MB
– RAID 1: 100 MB
– RAID 5: 100 MB
– RAID 6: 100 MB
– RAID 60: 100 MB
• For PERC 7, PERC 8, and PERC 9 controllers:
– RAID 0: 100 MB
– RAID 1: 100 MB
– RAID 5: 100 MB
– RAID 6: 100 MB
– RAID 10: 100 MB
– RAID 50: 100 MB
