Enumerating RAID Controllers
The following table lists the RAIDCFG options, parameters, and pre-dened arguments for enumerating RAID controllers.
Table 314. Enumerating RAID Controllers
Mandatory Options
and Arguments
Optional Parameters Valid Parameters
Arguments
Description
-ctrl or
controller
NA NA
Lists all the RAID controllers on the host system, along
with select property information. This option is
mandatory
Example:
raidcfg -ctrl
Controller_ID/Slot_ID: 4
Controller_PCI_ID: 9:0:0
Controller_Name: PERC H710P Adapter
Channels: 2
No.of Virtual_Disks: 17
Array_Disks:
0:0:1,0:1:1,0:2:1,0:3:1,0:4:1,0:5:1,
0:6:1, 0:7:1
Persistent Hot Spare: Disabled
Firmware Version: 21.2.0-007
Controller_Boot_Mode: 2 (Headless
continue on error)
Enable_Auto_Import: No
T10 Protection Info Capable: No
RAIDCFG Command successful!
-c or
controllerid
<valid
controller ID
number>
Displays the properties for the RAID controller with the
specied controller ID. This option combination is
mandatory.
Example:
raidcfg -ctrl -c=31
Controller_ID/Slot_ID: 31
Controller_PCI_ID: 7:0:0
Controller_Name: PERC FD33xS
Channels: 1
No.of Virtual_Disks: 1
Array_Disks:
0:0:1,0:2:1,0:3:1,0:4:1,0:7:1,0:8:1,0:1
0:1,0:12:1,0:14:1,0:15:1
Persistent Hot Spare: Disabled
Firmware Version: 25.2.2-0004
Preserved Cache: Not Available
Controller_Boot_Mode: 1 (BIOS continue
on error)
Enable_Auto_Import: Yes
T10 Protection Info Capable: Yes
Encryption Capable: Yes
Encryption Key Present: Yes
RAIDCFG Command successful!
Creating Virtual Disks
The following table lists the RAIDCFG options, parameters, and predened arguments for creating virtual disks.
NOTE: If you create a virtual disk on Windows PE, reboot the system.
