Mandatory command line options must be present in the command. Optional command line options can be typed in any order after
the mandatory options have been typed. Many options have both a short and long format. Short and long format options cannot be
used in the same command line instance.
Table below shows some examples of valid and invalid short and long format command line instances. For an explanation of the
specic order for each option, see RAID Conguration Utility Options And Arguments. For a list of frequently used RAID commands,
see Quick Reference To RAIDCFG Commands.
NOTE: Some of the following options or arguments might not be available on all systems.
Table 312. RAIDCFG Short and Long Format Options
Option Valid Arguments Short Description Mandatory or Optional
No option
-h
-?
or
/?
NA Displays general usage information for
the utility. The usage information consists
of a comprehensive list of valid options,
parameters, and arguments.
Optional.
See General Help for specic
usage information.
-ac or action
blink
Blinks the specied physical disks on the
specied controller.
See Blinking And Unblinking
Array Disks for specic
usage information.
ci
or
cancelinit
Cancels the slow or full initialization on
the selected virtual disk.
See Initializing Virtual Disks
for specic usage
information.
cc or consistencycheck Checks the consistency for a specied
virtual disk.
See Consistency Check For
Virtual Disk for specic
information.
ccc or
cancelconsistencycheck
Cancels the consistency check for a
specied virtual disk.
See Consistency Check For
Virtual Disk for specic
information.
chsk
or
changesecuritykey
Changes the encryption key of the
encryption-capable controller.
See Changing Encryption
Key for specic information.
crbd
or
cancelrebuild
Cancels the rebuild of the physical disk
associated with a specied virtual disk.
See Conguring Physical
Disk Rebuild for specic
information.
ctr
or
converttoraid
Congures the array disk as RAID.
See Conguring Array Disk
as RAID for specic
information.
csk
or
createsecuritykey
Creates encryption key for the
encryption-capable controller.
See Creating Encryption Key
for specic information.
