Option Sub-option Valid Arguments Description
Example 1 (to display the current SOL
conguration):
A:>syscfg solcfgparams
solcfgparams solenable=enable
solprivlevel=administrator
solcharaccum interval=25
solcharsend threshold=25
solbitrate=9600
Example 2 (to set the SOL conguration
parameters):
A:>syscfg solcfgparams
--solenable=disable
--solprivlevel=administrator
--solcharaccum interval=25
--solcharsend threshold=100
--solbitrate=9600 solcfgparams
solenable=disable
solprivlevel=administrator
solcharaccum interval=25
solcharsend threshold=100
solbitrate=9600
ssninfo
Table 304. ssninfo
Option Sub-option Valid Arguments Description
ssninfo
Displays information about the number of possible
active sessions and the number of currently active
sessions on all channels on the BMC. This option
cannot be replicated.
NOTE: All PowerEdge systems prior to
PowerEdge 12G systems.
--maxactivessns
NA Displays the maximum possible active BMC sessions.
This sub-option cannot be replicated.
--currentactivessns
NA
Displays the number of currently active sessions on
all channels of the BMC. This sub-option cannot be
replicated.
Example:
A:>syscfg ssninfo
currentactivessns=1
maxactivessns=4
useraction
Table 305. useraction
Option Sub-option Valid Arguments Description
useraction
Enables and disables BMC, sua, and lua user IDs.
This option can be replicated.
--userid
2–16, if your system
has a DRAC 5 controller
Species the BMC user ID. This sub-option can be
replicated.
137
