serialcfgparams
Table 298. serialcfgparams
Option Sub-option Valid Arguments Description
serialcfgparams
or scp
Congures and displays serial conguration
parameters. This option can be replicated.
--connectionmode basic, terminal
Sets the connection mode used to perform
IPMI messaging to the BMC. This sub-option
can be replicated.
--msgcomm noflowctrl,
rtscts
Sets the IPMI message communication ow
control. This suboption can be replicated.
--msgcommdtrhangup
NA Reports the IPMI message communication DTR
hang-up. This suboption cannot be replicated.
--msgcommbitrate 9600, 19200,
57600, 115200
Sets the IPMI message communication baud
rate in bits per second (bps). This sub-option
can be replicated.
--tmcfglineediting enable, disable
Sets the line editing value for terminal mode
conguration. This sub-option can be replicated.
--tmcfgdelctrl del, bksp
Sets the delete control value for terminal mode
conguration. This sub-option can be replicated.
--tmcfgechoctrl echo, noecho
Sets the echo control value for terminal mode
conguration. This sub-option can be replicated.
--tmcfghandshakectrl enable, disable
Sets the handshake control value for terminal
mode conguration. This sub-option can be
replicated.
--tmcfgnewlineseq noterm, crlf,
null, cr, lfcr,
1f
Sets the new line sequence value for terminal
mode conguration. This sub-option can be
replicated.
--
tmcfginputnewlineseq
cr, null
Sets the input new line sequence value for
terminal mode conguration. This sub-option
can be replicated.
Example (to display the current serial
conguration settings):
A:>syscfg serialcfgparams
serialcfgparams tmcfgdelctrl=del
tmcfgechoctrl=echo
tmcfghandshakectrl=enable
connectionmode=terminal
tmcfgnewlineseq=crlf
msgcommflowctrl=rtscts
tmcfginputnewlineseq=cr
msgcommdtrhangup=disable
msgcommbitrate=19200
tmcfglineediting=enable
