Option Sub-option Valid Arguments Description
--alertpolnum 1, 2, 3, 4
Species the alert policy entry number. This
sub-option can be replicated.
--alertpolstatus enable, disable
Enables or disables the alert policy specied
using the alertpolnum sub-option. This sub-
option can be replicated. This sub-option is
dependent on the alertpolnum sub-option.
Example: (to set the PEF conguration
parameters):
Example 1 (To congure the PEF so that the
system is powered down in response to a fan
failure event):
A:>syscfg pefcfgparams --filter=
fanfail--filteraction=powerdown
pefcfgparams filter=fanfail
filteraction=powerdown
Example 2 (To congure the PEF so that a PEF
alert is not sent to the destination IP address in
response to a chassis intrusion event):
A:>syscfg pefcfgparams --filter=
intrusion--filteralert=disable
pefcfgparams filter= intrusion
filteralert=disable
Table 294. pefcgparams
Option Sub-option Valid Arguments Description Applicable Systems
pefcfgparams
or pcp
Congures and displays PEF
conguration parameters. This option
can be replicated.
All PowerEdge systems
--filter fanfail,
voltfail,
discretevolt
fail,
tempwarn,
tempfail,
intrusion,
redundegrade
d,redunlost,
procwarn,
procfail,
powerwarn,
powerfail,
hardwarelogf
ail,
autorecovery
,
batterywarn,
batteryfail,
powerabsent,
procabsent,
systempowerw
arn,
Species a PEF value. This sub-option
can be replicated.
For a complete list of all possible PEF
messages along a description of each
event, see BMC Platform Events Filter
Alert Messages
NOTE: The fanfail option is
not supported on PowerEdge
10G systems.
130
