lcd1
Table 287. lcd1
Option Sub-option Valid Arguments Description
--lcd1
NA <string>
Sets the rst line of user-dened text on the
system LCD. This option can be replicated. For
more information on delimiters, see Command Line
Option Delimiters.
NOTE: Before setting user strings for --
lcd1 , ensure that --lcd is set to user.
lcd2
Table 288. lcd2
Option Sub-option Valid Arguments Description
--lcd1
NA <string>
Sets the second line of user-dened text on the
system LCD. This option can be replicated. For
more information on delimiters, see Command Line
Option Delimiters.
loaddefaults*
Table 289. loaddefaults*
Option Sub-option Valid Arguments Description
--loaddefaults*
NA NA
Restores the BMC to the defaults originally loaded
on the controller. This option is used to return the
BMC to a known-good state. This option cannot be
replicated.
NOTE: The NMI, power button, and SOL
defaults are not reset by using this option.
Example:
A:>syscfg --loaddefaults
Loading defaults...
nextboot
Table 290. nextboot
Option Sub-option Valid Arguments Description
--nextboot or --
OneTimeBootSeqDev
NA valid device name
(from the bootseq
option device list)
Sets the specied device as the rst device in
the boot order for the next boot cycle only. The
device must be a device from the bootseq
option device list. Run the bootseq option to
see a list of available device names. For more
information, see
--bootseq. This option is not
replicated.
