Option Sub-option Valid Arguments Description
--vlanid <string>
Sets the 12-bit VLAN ID. This sub-option can be
replicated.
--vlanpriority 0–7
Sets the VLAN priority value. This sub-option
can be replicated.
--macaddress
NA Displays the BMC MAC address. This sub-
option cannot be replicated.
--nicselection
NOTE: This option is
available only with the
appropriate installed license.
shared,
sharedfailove
r, dedicated,
sharedreceive
onall
Sets the operating mode of the NIC to shared,
sharedfailover, dedicated, or
sharedreceiveonall. Some of these
options are not applicable on certain systems.
NOTE:
This option is applicable on systems prior to
PowerEdge 12G systems. The
sharedreceiveonall argument is available
only on PowerEdge 11G systems.
--nicselection
NOTE: This option is
available only with the
appropriate installed license.
dedicated,
lom1, lom2,
lom3, lom4
Sets the operating mode of the iDRAC7 NIC to
dedicated, lom1, lom2, lom3, or lom4.
Some of these options are not applicable on
certain systems due to underlying hardware.
NOTE: This option is applicable on
PowerEdge 11G systems.
--nicselectionfailover
NOTE: This option is
available only with the
appropriate installed license.
none, lom1,
lom2, lom3,
lom4, all
Sets the operating mode of the NIC selection
failover to none, lom1, lom2, lom3, lom4, or
all. Some of these options are not applicable
on certain systems. due to underlying hardware.
NOTE: This option is applicable on
PowerEdge 12G systems.
--fullduplex
enable,
disable
Enables or disables full duplex on the RAC
network interface.
--autoneg enable,
disable
Enables or disables autonegotiation.
--speed 10,100
Sets the network interface speed to 10 or 100
Mbps.
--dnsdhcp enable,
disable
Enables or disables obtaining the DNS server IP
address through DHCP.
--dnsserver1 <ipaddress>
Sets the IP address of the primary DNS server
for domain name resolution.
--dnsserver2 <ipaddress>
Sets the IP address of the secondary DNS
server for domain name resolution.
--dnsregisterrac enable,
disable
Enables or disables binding of the RAC name to
the IP address.
--dnsracname <string>
Sets the name of the RAC.
--domainnamefromdhcp enable,
disable
Enables or disables getting the RAC domain
name through DHCP.
