Option Sub-option Valid
Arguments
Description Applicable Systems
Example:
A:>syscfg --kvmstatusonlcd=active
kvmstatusonlcd=active
lancfgparams
Table 283. lancfgparams
Option Sub-option Valid Arguments Description
lancfgparams or
lcp
Congures and displays LAN conguration
parameters. This option can be replicated.
--ipaddrsrc static, dhcp
Sets the IP address source for the LAN channel.
This sub-option can be replicated.
--ipaddress <ipaddress>
Sets the IP address for the LAN channel. This
sub-option cannot be replicated.
--subnetmask <subnetmask>
Sets the subnet mask for the LAN channel. This
sub-option can be replicated.
--gateway <gateway>
Sets the gateway for the LAN channel. This
sub-option can be replicated.
--commstring <string>
Sets the community string (maximum of 16
printable ASCII characters) used in a platform
event trap (PET). This sub-option can be
replicated.
--destipaddr <ipaddress>
Sets the destination IP address or Fully Qualied
Domain Name (FQDN) for the alert destination
specied with the alertdest sub-option.
The destipaddr sub-option is dependent on
the
alertdest sub-option. If the alertdest
sub-option is not specied on the command line,
the rst alert destination (alertdest=1) is
set with this IP address or FQDN. This sub-
option can be replicated.
NOTE: FQDN is applicable only for
destipaddr option and is supported
only on PowerEdge 12G systems.
Example 1 (to set the destination IP address):
A:>syscfg lcp --alertdest=1 --
destipaddr=192.168.100.15
Example 2 (to set the destination IP address as
FQDN):
A:>syscfg lcp --alertdest=1 --
destipaddr=xxx.yyy.com
--alertdest 1, 2, 3, 4
Sets the destination for the LAN alert. This sub-
option can be replicated.
--vlantag enable,
disable
Enables or disables VLAN tagging. This sub-
option can be replicated.
